Compact UNO

Compact UNO

The Compact Uno polyamide rope, composed of 16 strands, is impregnated to provide maximum protection against chemicals and starches. Although the rope is harder to splice due to its strength, the return is that it is highly resistant to elongation and abrasion. It is best suited for paper with low weight and machines operating at speeds up to 600 m/min. at 100 °C. Last but not least, you will appreciate the rope’s thermostabilization and maximum temperature load of 180 °C .

...read more

The Compact Uno polyamide rope, composed of 16 strands, is impregnated to provide maximum protection against chemicals and starches. Although the rope is harder to splice due to its strength, the return is that it is highly resistant to elongation and abrasion. It is best suited for paper with low weight and machines operating at speeds up to 600 m/min. at 100 °C. Last but not least…

Paper adhesion
Basic
Rope lifetime
Basic
Resistance to chemicals
Maximum
Paper weight
Low

The Compact Uno polyamide rope, composed of 16 strands, is impregnated to provide maximum protection against chemicals and starches. Although the rope is harder to splice due to its strength, the return is that it is highly resistant to elongation and abrasion. It is best suited for paper with low weight and machines operating at speeds up to 600 m/min. at 100 °C. Last but not least, you will appreciate the rope’s thermostabilization and maximum temperature load of 180 °C .

Inquiry form

By submitting the form, you agree to the privacy policy.

The Compact Uno polyamide rope, composed of 16 strands, is impregnated to provide maximum protection against chemicals and starches. Although the rope is harder to splice due to its strength, the return is that it is highly resistant to elongation and abrasion. It is best suited for paper with low weight and machines operating at speeds up to 600 m/min. at 100 °C. Last but not least, you will appreciate the rope’s thermostabilization and maximum temperature load of 180 °C .

DiameterWeight [g/m]
Roll length [m/ft]
Rope tension [kg]
8.5 mm
32.7600/1 96830 - 40
10 mm
37.7600/1 96840 - 50
11 mm
55.0500/1 64050 - 60
12 mm57.8400/1 31260

Show more
